| Motor Type |
Brose S Mag, brushless internal rotor, mid-drive mounting |
| Motor Power |
250W (continuous rated power) |
| Torque |
90Nm/66 ft. lb. |
| Battery |
706Wh, integrated, removable |
| Range |
35-115 miles – Depends on mode and terrain |
| Charge Time |
0-100% = 6.6hrs, 0-75% = 3.5hrs |
| Maximum Assistance Speed |
20 mph (US)/25 kph (EU) |
| Drivetrain |
Enviolo Automatiq intelligent auto-shifting hub |
| Final Drive |
Gates Carbon Drive belt |
| Frame |
Hydroformed aluminum, welded construction, internal routing |
| Fork |
Aluminum |
| Brakes |
Tektro hydraulic four-piston-caliper disc brakes front and rear, 203mm X 2.3mm “heavy-duty” rotors |
| Wheels |
27.5 x 35mm alloy rims and Sapim stainless steel spokes |
| Tires |
Schwalbe Super Moto-X 27.5 x 2.4-inch |
| LED Front Lighting |
LED Headtube Shield Signature light
LED Headlight
|
| LED Rear Lighting |
Integrated taillights with brake light |
| Controller |
Brose Display Allround |
| TFT Display |
1.5-inch, 240 x 240-pixel TFT display shows selected ride mode,
current speed, odometer/trip meter, battery charge level, and headlamp on/off status at a glance. |
| Storage Compartment |
A lockable, 620 cubic-centimeter storage compartment provides a convenient place to stow a lock or other small items you might wish to take along for the ride. Dimensions: 206mm (length) X 42mm (height) X 70mm (wide). |
| Fenders |
Integrated front and rear |
| Rack |
Integrated front and rear |
| Rack Capacity |
10kg capacity each, front & rear racks |
| Frame Sizes |
S, M, L, XL |
| Weight |
59.0 lb./26.8kg (Size Large) |
| Color Options |
Matte Vapor Silver/Gloss Burst Orange/Matte Black; Gloss
Midnight Black/Matte Black |
